IVTM Wheel Module

Size (mm x mm x mm) 138 x 116 x 53
Angle 70°
Angle between Holes - 36°
Diameter - 225.0 mm
Mounting - 2x Ø 26 mm
Operational range - 2 to 14 bar
Port Angle - 170°
Port thread - 1VG 8
Port thread 2 - Voss 203 Ø 6 x 1.5
Protection Class - IP 6K6K / 6K7 / 6K9K
Temperature range -40°C to +90°C
Type - Wheel Modul 2
Calculated Volume - (dm³)0.848
GTIN - 04057875295808
Weight - 0.2 kg
